B84113H0000B030

Power Line Filter Modules Overview

The B84113H0000B030 is a single-phase EMC line filter from the TDK B84113H series, rated for 3 A maximum current and 250 V AC/DC. Designed for 50/60 Hz operation, it features a two-stage filtering architecture with 4 mH inductance and 2 pF capacitance. The unit utilizes quick-connect terminals and chassis mounting. It operates within a temperature range of -25°C to 100°C, with a leakage current of 369 μA. Physical dimensions are 52 mm length, 89.5 mm depth, and 38 mm height.

Power Line Filter Modules Feature Summary

• Two-stage filtering configuration for enhanced noise suppression
• Chassis mount design with quick-connect termination
• RoHS compliant construction

Power Line Filter Modules Applications

• Single-phase power line EMI suppression
• General purpose EMC filtering for electronic equipment
• Industrial control system input stages

Power Line Filter Modules Procurement Notes

Verify the specific suffix code against official TDK documentation to confirm terminal type and electrical ratings. Ensure the application voltage does not exceed 250 V AC/DC and the continuous current remains within the 3 A limit. Confirm chassis mounting compatibility and thermal management requirements for the operating temperature range.

Power Line Filter Modules Selection Notes

Select this component when a compact, two-stage solution is required for single-phase applications. The low capacitance value minimizes leakage current compared to higher-capacitance alternatives. Verify that the quick-connect terminal style matches the mating connector specifications on the target PCB or wiring harness.

Power Line Filter Modules Part Context

This part belongs to the TDK B84113H series of power line filters. The series offers various current ratings and termination options. This specific model represents the 3 A variant within the lineup, distinguished by its specific inductance and capacitance values tailored for general-purpose interference reduction.

Power Line Filter Modules Replacement Considerations

Consult official TDK cross-reference lists for verified substitutes. Ensure any replacement maintains the same two-stage topology, current rating, and terminal interface to preserve mechanical and electrical compatibility.
