B84113H0000G125

Power Line Filter Modules Overview

The EPCOS B84113H0000G125 is a single-phase EMC/EMI line filter module designed for power line applications. It supports a rated AC voltage of 250V and a rated DC voltage of 250V, with a continuous current rating of 25A at 50Hz or 60Hz frequencies. The component features a two-stage filtering configuration and utilizes screw termination style with M5 threaded posts for secure mounting. It is engineered to provide effective electromagnetic interference suppression in both AC and DC systems.

Power Line Filter Modules Feature Summary

• Provides two-stage EMI/EMC suppression for power lines
• Supports snap-in DIN-rail TH35 installation
• Designed for single-phase or DC system integration

Power Line Filter Modules Applications

• Power line EMI suppression
• Single-phase AC/DC system filtering
• DIN-rail mounted industrial electronics

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version for the B84113H0000G125 to confirm mechanical dimensions and terminal specifications. Ensure compatibility with the target DIN-rail type (TH35) and verify that the 25A current rating meets the operational requirements of the intended circuit. Confirm compliance certifications such as UL and CSA are valid for the specific application region.

Power Line Filter Modules Selection Notes

Select this component when a compact, two-stage EMI filter is required for 25A single-phase applications. The chassis mount design with screw terminals offers robust connectivity compared to PCB-only options. Consider the physical height of 53mm for enclosure space planning. Verify that the leakage current characteristics align with safety standards for the end equipment.

Power Line Filter Modules Part Context

This part belongs to the TDK EPCOS B84113H series of power line filters. These modules are standardized components used for noise reduction in electrical networks. The manufacturer specializes in passive electronic components for industrial and consumer applications, ensuring reliability through established manufacturing processes for EMI suppression devices.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the B84113H series with different current ratings if load conditions vary. Verify pinout and mounting hole patterns before substituting with other manufacturers' single-phase filters to ensure mechanical fit.
