B84142A0010R000

Power Line Filter Modules Overview

The B84142A0010R000 is a single-phase EMC power line filter manufactured by EPCOS (TDK Electronics). It features a rated current of 10 A and supports voltages up to 250 V AC/DC at 60 Hz. The unit utilizes a flange mounting style with screw terminals for secure connection. Designed for industrial applications, it operates within a temperature range of -25°C to +100°C and weighs approximately 550 g.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for single-phase power lines
• Features robust flange mounting for stable chassis installation
• Utilizes block terminal connections for reliable electrical interfacing

Power Line Filter Modules Applications

• Power electronics converter systems
• Industrial motor drive units
• General purpose power supply filtering

Power Line Filter Modules Procurement Notes

Verify the specific suffix code against official TDK/EPCOS documentation to confirm exact ratings and certifications. Ensure the selected variant matches the required voltage and current specifications for the target application. Cross-reference datasheets for compliance standards such as UL, CUL, CSA, and EN before finalizing procurement decisions.

Power Line Filter Modules Selection Notes

Select this component based on its 10 A current capacity and 250 V AC/DC rating. Consider the physical dimensions and weight when designing the enclosure. Verify that the operating temperature range meets the environmental requirements of the installation site. Confirm compatibility with existing mounting hardware and terminal types.

Power Line Filter Modules Part Context

This component belongs to the B84142A series of EMC filters designed for converters and power electronics. The series offers various current ratings and configurations to suit different industrial needs. EPCOS, now part of the TDK Group, specializes in these passive electronic components for noise suppression.

Power Line Filter Modules Replacement Considerations

Consult official substitution lists for direct equivalents. Ensure any replacement maintains identical current, voltage, and mounting specifications. Verify that alternative parts meet the same regulatory certifications required for the original design.
