B84143A0150R105 is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists EPCOS - TDK Electronics. Its product description is LINE FILTER 520/300VAC 150A CHAS. Review the specifications below when checking this part for your BOM.
Power Line Filter Modules specifications for B84143A0150R105
- Description：LINE FILTER 520/300VAC 150A CHAS
- Series：B84143A
- Mfr：EPCOS - TDK Electronics
- Package：Bulk
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：520V, 300V
- Current：150 A
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：cUR, ENEC, UR
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Power Line Filter Modules datasheet and documents for B84143A0150R105
Power Line Filter Modules Overview
The B84143A0150R105 is a three-phase EMC/EMI line filter manufactured by TDK (EPCOS). It supports rated voltages of 520 VAC and 300 VAC at frequencies of 50 Hz and 60 Hz. The unit handles a maximum current of 150 A with a leakage current of 5 mA. It features a metal case construction, chassis mounting style, and terminal block termination. The component operates within a temperature range of -25°C to +100°C and weighs approximately 2.608 kg.
Power Line Filter Modules Feature Summary
- Three-phase filtering capability for delta systems
- Metal case construction for durability
- Terminal block termination for secure connection
Power Line Filter Modules Applications
- Regenerative drive systems
- Industrial power conditioning
- Equipment requiring IEC/TS 62578 compliance
Power Line Filter Modules Procurement Notes
Verify the specific part number suffix against official TDK documentation to confirm exact electrical ratings and mechanical dimensions. Ensure compatibility with the target system's voltage and current requirements before integration. Confirm certification status such as UL or CSA if required for the end application.
Power Line Filter Modules Selection Notes
Select this model for applications requiring high-current handling up to 150 A in three-phase configurations. Consider the chassis mount style and terminal block interface for installation constraints. Evaluate thermal management needs given the operating temperature range and physical mass of the metal housing.
Power Line Filter Modules Part Context
This component belongs to the B84143A series of power line filters designed for industrial environments. The series covers a wide range of current ratings from 8 A to 150 A. These filters are engineered to suppress electromagnetic interference in AC power lines, ensuring compliance with emission standards.
Power Line Filter Modules Replacement Considerations
Consult official TDK substitution guides for verified alternatives. Generic cross-references may not match the specific electrical characteristics or mechanical footprint of this high-current industrial filter.
