B84143V0016R127

Power Line Filter Modules Overview

The B84143V0016R127 is a three-phase EMC sine-wave line filter manufactured by EPCOS - TDK Electronics. It features a rated AC voltage of 520 V (phase-to-phase) and supports a continuous current of 16 A. The device operates within a frequency range of 50 to 60 Hz and is designed for chassis mounting. This component serves as an output filter for converters, providing electromagnetic compatibility in drive applications.

Power Line Filter Modules Feature Summary

• Provides sine-wave output filtering for converter applications
• Ensures electromagnetic compatibility through two-stage filtering
• Features UL-certified insulation systems for safety compliance

Power Line Filter Modules Applications

• Converter output filtering
• Drive system noise suppression
• Inverter application EMC mitigation

Power Line Filter Modules Procurement Notes

Verify the specific suffix R127 against official TDK documentation to confirm insulation system certification details. Ensure the chassis mounting configuration matches the installation requirements. Cross-reference the 16A rating with actual load conditions to prevent thermal overload during operation.

Power Line Filter Modules Selection Notes

Select this model when a dedicated sine-wave filter is required for three-phase converters operating at 520V. The chassis mount design suits industrial enclosures. Confirm that the 16A current capacity aligns with the motor or load specifications to ensure reliable performance without derating issues.

Power Line Filter Modules Part Context

This component belongs to the B84143V series of Sineformer filters from EPCOS. These filters are engineered for drive and inverter applications, utilizing shielded motor cables to reduce common-mode voltages. The series integrates high-performance components to meet strict EMC standards while protecting downstream equipment from electrical noise.

Power Line Filter Modules Replacement Considerations

Consult official TDK substitution guides for compatible alternatives. Verify that any substitute maintains the same three-phase configuration, 16A current rating, and 520V voltage specification to ensure functional equivalence in the circuit.
