B84144A0025R000

Power Line Filter Modules Overview

The EPCOS B84144A0025R000 is a four-line power line EMC filter belonging to the RTHB series. It features a chassis mount design with block terminal termination style. The component supports a rated AC voltage of 500V and a rated DC voltage of 500V, with a rated current capacity of 25A. It operates within a temperature range of -25°C to +100°C.

Power Line Filter Modules Feature Summary

• Four-line filtering architecture designed for comprehensive electromagnetic interference suppression in complex power systems.

Power Line Filter Modules Applications

• Frequency converters for motor drives
• Elevator control systems
• Industrial pump drives
• Traction systems

Power Line Filter Modules Procurement Notes

Verify the specific suffix 'R000' against official TDK documentation to confirm exact internal configuration and compliance certifications. Ensure mechanical mounting dimensions and terminal block specifications match the target enclosure design before procurement.

Power Line Filter Modules Selection Notes

Select this component when four-line filtering is required for high-current applications up to 25A. Confirm that the 500V rating aligns with the system's peak voltage requirements and that chassis mounting is feasible within the assembly constraints.

Power Line Filter Modules Part Context

This part belongs to the B84144A series of four-line filters intended for converters and power electronics. It is manufactured by EPCOS, now part of TDK Electronics, which specializes in electronic components for automotive, industrial, and consumer markets.

Power Line Filter Modules Replacement Considerations

Consult official TDK cross-reference lists for verified substitutes. Generic equivalents may not replicate the specific four-line topology or thermal performance characteristics required for certified installations.
