B84742A0055R190

Power Line Filter Modules Overview

The B84742A0055R190 is a single-phase EMI/EMC power line filter manufactured by TDK Electronics. It features a chassis mount design with terminal block termination, rated for 55 A current and 500 VAC / 1 kVDC voltages. The unit operates at 50 Hz or 60 Hz frequencies with a leakage current of 7.7 mA. Certified under UL, CSA, and IEC/EN standards, it belongs to the B84742A-R190 series.

Power Line Filter Modules Feature Summary

• Provides effective electromagnetic interference mitigation for single-phase AC and DC systems
• Features robust chassis mounting construction with terminal block connections
• Complies with major international safety and EMC certification standards

Power Line Filter Modules Applications

• Photovoltaic inverters
• Industrial automation equipment
• Data center power distribution units

Power Line Filter Modules Procurement Notes

Verify the complete part number including the suffix R190 to ensure correct termination style and certification compliance. Confirm voltage ratings match system requirements before integration. Check RoHS status and REACH declarations against specific project constraints. Validate physical dimensions for chassis cutout compatibility during mechanical design phases.

Power Line Filter Modules Selection Notes

Select this component when high current handling up to 55 A is required in a single-phase configuration. Ensure the 1 kVDC rating aligns with the maximum DC bus voltage of the application. Consider the 7.7 mA leakage current limit for sensitive medical or precision instrumentation environments where lower leakage might be necessary.

Power Line Filter Modules Part Context

This filter belongs to the B84742A series designed for industrial power applications. TDK Electronics acquired EPCOS, integrating these components into their broader portfolio. The series supports renewable energy and industrial sectors requiring reliable EMI suppression in compact chassis-mounted formats.

Power Line Filter Modules Replacement Considerations

Consult official TDK documentation for direct cross-references within the B84742A family. Verify that substitute models maintain identical terminal block configurations and certified voltage ratings.
