B86301U0320S000

Power Line Filter Modules Overview

The B86301U0320S000 is a three-phase delta-connected EMC/EMI line filter module manufactured by TDK Electronics. Designed for chassis mounting, this single-stage unit supports a rated current of 320 A at AC frequencies between 50 and 60 Hz. It features a maximum relative-to-phase voltage rating of 520 V and an inductance value of 18 µH. The component utilizes terminal post termination and operates within a temperature range of -25°C to 100°C. It holds cURus certification and complies with RoHS3 standards.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for three-phase power systems
• Engineered for robust chassis mounting applications
• Utilizes terminal post connections for secure electrical interfacing

Power Line Filter Modules Applications

• Industrial machinery power distribution
• General purpose AC power filtering
• Electrical equipment requiring EMI mitigation

Power Line Filter Modules Procurement Notes

Verify the complete part number including all suffix characters against official manufacturer documentation prior to ordering. Confirm that the specific configuration matches the required installation environment and electrical specifications. Ensure compatibility with existing chassis mounting hardware and terminal post dimensions. Cross-reference the latest datasheet version to validate current production status and any potential design changes or marking updates.

Power Line Filter Modules Selection Notes

Select this component when a high-current three-phase solution is required for industrial environments. The delta connection configuration must align with the system topology. Verify that the 320 A current rating and 520 V voltage limits exceed the operational requirements of the target application. Consider the operating temperature range and physical mounting constraints during the design phase to ensure proper integration.

Power Line Filter Modules Part Context

This module belongs to the B86301 series of power line filters from TDK Electronics. The series offers various configurations for different current ratings and connection types. These components are designed to meet stringent electromagnetic compatibility standards for industrial and commercial power applications, ensuring stable operation of connected electronic circuits.

Power Line Filter Modules Replacement Considerations

Consult official TDK Electronics substitution guides for verified alternative part numbers. Do not assume cross-compatibility based on similar ratings alone. Verify mechanical dimensions and electrical characteristics against the original specification sheet before implementing any substitute component.
