B86306A0022R000

Power Line Filter Modules Overview

The B86306A0022R000 is a three-phase (Delta) EMC/EMI line filter manufactured by TDK. It features a rated current of 22 A and a rated voltage of 520 VAC at 50/60 Hz. The unit utilizes a single-stage design with terminal block and wire lead connections. Typical electrical characteristics include a relative voltage drop of 3.4%, typical resistance of 12 mΩ, and typical inductance of 1.13 mH.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression for three-phase power systems
• Utilizes copper wire winding construction for reliable performance
• Supports connection via terminal blocks and wire leads

Power Line Filter Modules Applications

• Industrial motor drive systems
• Three-phase power supply filtering
• Electromagnetic compatibility compliance in industrial equipment

Power Line Filter Modules Procurement Notes

Verify the specific part number B86306A0022R000 against official TDK documentation to confirm ratings and physical dimensions. Ensure the application environment matches the 520VAC and 22A specifications. Check for any recent brand transition notices regarding EPCOS components within the TDK portfolio before finalizing procurement orders.

Power Line Filter Modules Selection Notes

Select this component when designing three-phase circuits requiring Delta configuration EMI filtering. Confirm that the system voltage does not exceed 520VAC and the load current remains within the 22A limit. Evaluate the required inductance value of approximately 1.13mH for effective noise attenuation in the target frequency range.

Power Line Filter Modules Part Context

This component belongs to the TDK power line filter module series. TDK acquired EPCOS, integrating its passive component portfolio. This specific model represents a standard industrial-grade filter designed for robust operation in demanding electrical environments where harmonic distortion and noise must be minimized.

Power Line Filter Modules Replacement Considerations

Consult official TDK substitution guides for verified equivalents. Cross-reference technical parameters such as inductance, current rating, and mounting style to ensure functional compatibility without modifying the existing circuit layout.
