BAA5670001

Oscillators Overview

The BAA5670001 is a standard clock oscillator manufactured by TXC Corporation, designed for surface-mount applications. It operates at a fundamental frequency of 156.25 MHz and requires a supply voltage of 3.3 V. The component utilizes the LVPECL output format to ensure signal integrity in high-speed digital systems. It supports an industrial operating temperature range from -40°C to +85°C. The device is RoHS compliant and features a compact SMD package suitable for automated assembly processes.

Oscillators Feature Summary

• Generates a precise 156.25 MHz clock signal using LVPECL output interface
• Operates reliably within an extended industrial temperature range of -40°C to +85°C
• Designed for direct surface-mount integration into printed circuit boards

Oscillators Applications

• High-speed serial communication interfaces requiring stable clock sources
• Data acquisition systems needing precise timing synchronization
• Telecommunications equipment utilizing LVPECL compatible logic families

Oscillators Procurement Notes

Verify the specific output configuration and pinout compatibility with the target circuit design before procurement. Confirm that the 3.3V supply rail meets the current requirements of the oscillator. Ensure the PCB layout adheres to the manufacturer's guidelines for LVPECL signals to maintain performance standards.

Oscillators Selection Notes

Select this component when a fixed 156.25 MHz frequency is required for system synchronization. The LVPECL output is suitable for applications demanding low jitter and high noise immunity. Consider the thermal environment to ensure operation remains within the specified -40°C to +85°C range during all operational phases.

Oscillators Part Context

This part belongs to the family of standard clock oscillators produced by TXC Corporation. It serves as a dedicated timing solution for electronic systems requiring a stable reference frequency. The device replaces discrete crystal and amplifier circuits by providing a complete, pre-tuned oscillator solution in a single surface-mount package.

Oscillators Replacement Considerations

No public confirmed substitute part numbers are available.
