Product Detailed Parameters
- Description：DIODE STANDARD 250V 200MA SOD323
- Series：-
- Mfr：ANBON SEMICONDUCTOR (INT'L) LIMITED
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：250 V
- Current - Average Rectified (Io)：200mA
- Voltage - Forward (Vf) (Max) @ If：1.25 V @ 200 mA
- Speed：Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr)：50 ns
- Current - Reverse Leakage @ Vr：100 nA @ 250 V
- Capacitance @ Vr, F：5pF @ 0V, 1MHz
- Mounting Type：Surface Mount
- Package / Case：SC-76, SOD-323
- Supplier Device Package：SOD-323
- Operating Temperature - Junction：-55°C ~ 150°C
- Grade：-
- Qualification：-
Download product information
Overview
The BAV21WS is a high-voltage silicon signal diode manufactured by Anbon Semiconductor. It is designed for general-purpose switching applications, featuring a compact SOD-123 surface-mount package. The device supports a repetitive peak reverse voltage of 250 V and a continuous forward current of 0.2 A. Its planar technology construction ensures reliable performance in industrial equipment and consumer electronics.
Feature Summary
- High-voltage capability suitable for demanding switching environments
- Compact SOD-123 surface-mount package design
- Planar technology construction for reliability
Applications
- General purpose switching in industrial equipment
- Protection circuits in digital voltmeters
- Video output stages in color television sets
Procurement Notes
Verify the specific manufacturer source, as the BAV21WS designation appears linked to Anbon Semiconductor in distributor records while standard equivalents are widely available from other vendors. Confirm package details and electrical ratings against official datasheets before integration. Ensure compliance with RoHS standards if required for the target application.
Selection Notes
Select this component for applications requiring a 250 V reverse voltage rating in a small surface-mount footprint. Compare switching speed and forward current specifications against circuit requirements. Consider availability and lead times from authorized distributors when planning production schedules.
Part Context
The BAV21WS belongs to the BAV series of general-purpose switching diodes. These devices are fabricated using planar technology and are commonly used in low-power signal processing and protection roles. The series includes variants like the BAV20W, offering similar functionality with different voltage ratings.
Replacement Considerations
The BAV20W is a documented alternative within the same family, sharing identical physical dimensions and basic electrical characteristics but differing in maximum reverse voltage ratings. Verify pinout compatibility and thermal performance when substituting.
