BAV99DW

Overview

The BAV99DW is a general-purpose diode array manufactured by Shenzhen Slkormicro Semicon Co., Ltd. in the SOT-363 (SC-88) surface-mount package. It features two internally connected serial diodes with a maximum DC reverse voltage of 75 V and an average rectified current of 150 mA per diode. The device exhibits a forward voltage of 1.25 V at 150 mA, a reverse leakage current of 2.5 µA at 75 V, and a reverse recovery time of 4 ns. Operating junction temperature ranges from -65°C to 150°C.

Feature Summary

• Dual internal series connection for compact circuit integration
• Fast switching capability with low reverse recovery time
• High thermal stability across extended operating temperatures

Applications

• General purpose signal switching
• Clamping and protection circuits
• Logic level shifting

Procurement Notes

Verify manufacturer identification as Shenzhen Slkormicro Semicon Co., Ltd. Confirm package type matches SOT-363 specifications. Ensure datasheet alignment for electrical parameters including 75V reverse voltage and 150mA current ratings. Validate RoHS compliance status prior to procurement.

Selection Notes

Select this component for applications requiring dual diode functionality in minimal space. The SOT-363 package offers board area efficiency compared to discrete single diodes. Consider the 4ns reverse recovery time for high-speed signal processing requirements within the specified voltage and current limits.

Part Context

This part belongs to the BAV99 family of general-purpose diode arrays. It serves as a surface-mount alternative to through-hole discrete diodes, providing integrated dual-diode solutions for modern electronics manufacturing. The SOT-363 packaging supports automated assembly processes common in consumer and industrial electronics production lines.

Replacement Considerations

BAV99BRW-TP by Micro Commercial Components is a verified substitute with identical electrical characteristics and SOT-363 packaging.
