BB-106.250MBE-T

Oscillators Overview

The BB-106.250MBE-T is a standard crystal oscillator (XO) manufactured by TXC Corporation, operating at a fundamental frequency of 106.25 MHz. It utilizes LVPECL output signaling and functions with a 3.3V supply voltage. The device features enable/disable control capabilities and maintains a frequency stability of ±50 ppm. Designed for surface-mount installation, it is housed in a compact 6-SMD, no-lead package measuring 7.00mm x 5.00mm x 1.50mm. The component supports an operating temperature range from -40°C to 85°C and draws a maximum supply current of 80mA.

Oscillators Feature Summary

• LVPECL differential output interface for high-speed signal integrity
• Integrated enable and disable functionality for power management
• Surface-mount construction in a 6-pin no-lead SMD package

Oscillators Applications

• High-speed digital clock distribution systems
• Data communication equipment requiring precise timing references
• Industrial control systems operating within extended temperature ranges

Oscillators Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required voltage levels and output types. Confirm that the selected variant matches the necessary frequency stability and operational temperature specifications for the target application environment. Ensure compliance with RoHS3 regulations if environmental standards are mandated. Cross-reference the manufacturer part number with distributor listings to confirm availability and lead times prior to finalizing procurement orders.

Oscillators Selection Notes

Select this component when LVPECL outputs are required for low-voltage differential signaling applications. Consider the ±50 ppm stability requirement against system jitter tolerance. Evaluate the 7.00mm x 5.00mm footprint against PCB space constraints. Verify that the 3.3V supply voltage aligns with the system power architecture. Assess the enable/disable feature necessity for dynamic power saving requirements in the design.

Oscillators Part Context

This oscillator belongs to the BB Series of standard clock oscillators from TXC Corporation. The series provides various frequency options in standardized packages. The BB-106.250MBE-T specifically addresses the need for 106.25 MHz timing signals in modern electronic designs. It represents a solution for applications demanding reliable clock generation with defined electrical characteristics and mechanical dimensions.

Oscillators Replacement Considerations

Direct substitutes may include other 106.25 MHz LVPECL oscillators from different manufacturers, provided pinout and electrical parameters match. Verify equivalent frequency stability and operating temperature ranges before substitution. Check for compatible packaging and mounting requirements to ensure seamless integration into existing PCB layouts without redesign.
