Product Detailed Parameters
- Description：MULTIFUNCTION SINGLE-PHASE FULL-
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Motor Type - Stepper：-
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Controller - Commutation, Direction Management
- Output Configuration：Half Bridge (2)
- Interface：PWM
- Technology：DMOS
- Step Resolution：-
- Applications：Fan Motor Driver
- Current - Output：200mA
- Voltage - Supply：4.5V ~ 16V
- Voltage - Load：18V
- Operating Temperature：-40°C ~ 105°C
- Mounting Type：Surface Mount
- Package / Case：10-UFDFN Exposed Pad
- Supplier Device Package：VSON010X3030
- Grade：-
- Qualification：-
Download product information
Overview
The BD61247NUX-E2 is a single-phase brushless DC motor driver manufactured by ROHM Semiconductor. It operates within a supply voltage range of 4.5 V to 16 V, with a nominal operating voltage of 12 V. The device delivers an output current of 1.2 A and features two half-bridge outputs. It supports PWM interfaces with operating frequencies between 15 kHz and 50 kHz. The component functions in temperatures from -40°C to +105°C and is housed in a VSON-10 package.
Feature Summary
- Integrates H-bridge power DMOS FETs for single-phase full-wave driving
- Utilizes PWM soft switching technology to reduce motor noise
- Supports standard PWM interface for control signal input
Applications
- Brushless DC motor control in consumer electronics
- Fan motor drivers requiring quiet operation
- Single-phase motion control systems
Procurement Notes
Verify the specific suffix E2 against the official ROHM datasheet to confirm compliance with environmental standards and pinout compatibility. Ensure the ordering quantity aligns with the manufacturer's reel packaging requirements. Cross-reference the part number with authorized distributors to confirm current availability and production lifecycle status before finalizing procurement plans.
Selection Notes
Select this component when a compact solution for single-phase BLDC motors is required. The VSON-10 package suits space-constrained designs. Verify that the load voltage does not exceed 18 V and that the thermal environment remains within the specified -40°C to +105°C range. Confirm that the system logic levels are compatible with the PWM interface inputs.
Part Context
This part belongs to ROHM's PMIC Motor Driver category, specifically designed for brushless DC applications. It integrates power and control functions into a single chip, simplifying the design of motor drive circuits. The series focuses on reducing acoustic noise through advanced switching techniques while maintaining high efficiency in small form factors.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Consult the official ROHM replacement guide or contact the manufacturer directly for qualified alternatives.
