Product Detailed Parameters
- Description：IC MOTOR DRIVER 8V-26.4V 28VQFN
- Series：-
- Mfr：Rohm Semiconductor
- Package：Tape & Reel (TR),Cut Tape (CT)
- Motor Type - Stepper：-
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Driver
- Output Configuration：Pre-Driver - Half Bridge (3)
- Interface：Logic
- Technology：Power MOSFET
- Step Resolution：-
- Applications：General Purpose
- Current - Output：5mA
- Voltage - Supply：8V ~ 26.4V
- Voltage - Load：8V ~ 26.4V
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：28-VFQFN Exposed Pad
- Supplier Device Package：VQFN028V5050
- Grade：-
- Qualification：-
Download product information
Overview
The BD63002MUV-E2 is a three-phase brushless DC motor pre-driver manufactured by Rohm Semiconductor. It operates within a supply voltage range of 8V to 26.4V and delivers an output current of 15mA. Designed for surface-mount installation, the component utilizes a 28-pin VQFN package with dimensions of 5.0x5.0mm. The device supports PWM control modes and functions effectively across an operating temperature range of -40°C to +85°C.
Feature Summary
- Generates drive signals based on Hall sensor inputs for commutation
- Supports Nch-Nch MOS transistor configurations via built-in boost circuit
- Integrates comprehensive protection mechanisms including thermal shutdown and over-voltage lockout
Applications
- Office automation equipment
- Fan motors
- Optical disk drives
Procurement Notes
Verify that the specific suffix E2 corresponds to RoHS3 compliance requirements for your target market regulations. Confirm the package variant matches the required footprint for PCB layout. Ensure the selected supplier provides traceable documentation matching the manufacturer's part number BD63002MUV-E2 to guarantee authenticity and performance consistency.
Selection Notes
Select this component when designing systems requiring precise commutation control for three-phase brushless motors using Hall sensors. It is suitable for applications demanding compact form factors due to its small VQFN packaging. Consider the integrated protection features for robust operation in environments prone to electrical noise or transient voltage spikes.
Part Context
This pre-driver belongs to Rohm’s series of motor control ICs designed for high reliability and efficiency. It complements external power FETs to create complete drive stages. The product line targets cost-effective solutions for consumer electronics and industrial appliances requiring reliable motion control capabilities.
Replacement Considerations
Consult official substitution lists for compatible pre-drivers within the same family. Verify pin compatibility and electrical specifications before integrating alternative components into existing designs.
