BD63520AEFV-E2

$3.51

Description：IC MTR DRV BIPOLR 8-28V 28HTSSOP
Series：-
Mfr：Rohm Semiconductor
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:665c00d73385 Category: Motor Drivers, Controllers Brand: Rohm Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC MTR DRV BIPOLR 8-28V 28HTSSOP
Series：-
Mfr：Rohm Semiconductor
Package：Tape & Reel (TR),Cut Tape (CT)
Motor Type - Stepper：Bipolar
Motor Type - AC, DC：-
Function：Driver - Fully Integrated, Control and Power Stage
Output Configuration：Half Bridge (4)
Interface：Parallel
Technology：DMOS
Step Resolution：1, 1/2, 1/4, 1/16
Applications：General Purpose
Current - Output：2A
Voltage - Supply：8V ~ 28V
Voltage - Load：8V ~ 28V
Operating Temperature：-25°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：28-VSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package：28-HTSSOP-B
Grade：-
Qualification：-

Download product information

BD63520AEFV-E2

Overview

The BD63520AEFV-E2 is a micro-stepping stepper motor driver manufactured by ROHM Semiconductor. It supports 1/16 µ-step resolution for precise motion control. The device features a rated supply voltage of 36V and delivers a DC output current of 2.0A. It operates within a load voltage range of 8V to 28V. The component utilizes an HTSSOP-B-28 package with SMD/SMT mounting style. Power dissipation is rated at 4.7W, with a quiescent supply current of 2mA. Operating temperatures span from -25°C to +85°C.

Feature Summary

Supports high-resolution 1/16 micro-stepping for smooth motor operation
Integrates low-power bipolar PWM constant current drive architecture
Provides dual-channel output capability for bipolar stepper motors

Applications

Industrial automation equipment requiring precise positioning
Motion control systems utilizing small to medium-sized bipolar stepper motors
General purpose motor driver circuits in consumer electronics

Procurement Notes

Verify the specific suffix E2 against official ROHM documentation to confirm pinout compatibility and thermal characteristics. Ensure the HTSSOP-B-28 package dimensions align with PCB layout requirements. Confirm moisture sensitivity level handling procedures are followed during assembly to prevent package damage. Cross-reference the 36V rating with system power supply limits to avoid overvoltage conditions.

Selection Notes

Select this component when 1/16 micro-stepping resolution is required for reduced vibration and noise. The 2.0A output current suits applications driving small to medium bipolar stepper motors. Consider the 36V supply rating for systems requiring higher voltage headroom. The integrated PWM constant current drive simplifies design compared to discrete solutions. Evaluate the -25°C to +85°C operating range against environmental constraints.

Part Context

This part belongs to ROHM's series of micro-stepping stepper motor drivers designed for efficient motion control. It integrates control logic and power stages into a single IC, reducing external component count. The BD63520AEFV-E2 variant specifically targets applications needing high resolution and moderate current capacity within a compact surface-mount package.
