Product Detailed Parameters
- Description：CONN EDGE SGL FMALE 10POS 0.059
- Series：BEC
- Mfr：Yamaichi Electronics
- Package：Tape & Box (TB)
- Card Type：Non Specified - Single Edge
- Gender：Female
- Number of Positions/Bay/Row：-
- Number of Positions：10
- Card Thickness：0.047" (1.20mm)
- Number of Rows：1
- Pitch：0.059" (1.50mm)
- Read Out：Dual
- Features：Board Guide, Solder Retention
- Mounting Type：Surface Mount, Right Angle
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：30.0µin (0.76µm)
- Contact Type：-
- Color：Black
- Flange Feature：-
- Operating Temperature：-40°C ~ 80°C
Download product information
Overview
The BECPOW-1.5-10-S9-AF-REDC1 is a standard card edge connector manufactured by Yamaichi Electronics, designed for module applications. It features a single row with 10 positions and a 1.50 mm pitch. The connector utilizes gold plating on the contacts and is housed in black liquid crystal polymer (LCP). It supports a current rating of 1.5 A per pin and offers an insulation resistance of 250 MOhms. The maximum operating temperature is rated at +85°C.
Feature Summary
- Designed specifically for power module applications
- Utilizes liquid crystal polymer housing material
- Features gold-plated contacts for reliable connection
Applications
- Module application power connections
- Automotive electronics systems
- Standard card edge interface circuits
Procurement Notes
Verify the specific suffix codes against official Yamaichi documentation to ensure correct housing color and contact configuration. Confirm that the 1.5A current rating aligns with your thermal management requirements. Check for RoHS compliance status through the manufacturer's latest datasheet before finalizing procurement specifications.
Selection Notes
Select this component when a 10-position, 1.50mm pitch card edge connector is required for power delivery. Ensure the design accommodates the LCP housing material properties and the specified 85°C temperature limit. Verify that the single-row female configuration matches the mating board edge geometry.
Part Context
This part belongs to the BECPOW series of power connectors from Yamaichi Electronics. The series is characterized by its suitability for high-reliability module applications. The model number indicates specific attributes such as position count, pitch, and contact plating, distinguishing it from other series like IC sockets or QFP test sockets.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided data. Consult Yamaichi Electronics directly for cross-reference recommendations if this specific model is unavailable.
