BJA2500001

Description：XTAL OSC VCXO 125.0000MHZ LVPECL
Series：BJ
Mfr：TXC CORPORATION
Package：Tape & Reel (TR)

SKU:f977a66489a2 Category: Oscillators Brand: TXC CORPORATION

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

BJA2500001 is listed in the Oscillators range at ChipApex. The manufacturer field lists TXC CORPORATION. Its product description is XTAL OSC VCXO 125.0000MHZ LVPECL. Review the specifications below when checking this part for your BOM.

Oscillators specifications for BJA2500001

Description：XTAL OSC VCXO 125.0000MHZ LVPECL
Series：BJ
Mfr：TXC CORPORATION
Package：Tape & Reel (TR)
Base Resonator：Crystal
Type：VCXO
Frequency：125 MHz
Function：Enable/Disable
Output：LVPECL
Voltage - Supply：3.3V
Frequency Stability：±20ppm
Absolute Pull Range (APR)：±50ppm
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：-
Ratings：-
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)：0.059" (1.50mm)
Supplier Device Package：-

Oscillators datasheet and documents for BJA2500001

BJA2500001

Oscillators Overview

The BJA2500001 is a Voltage Controlled Crystal Oscillator (VCXO) manufactured by TXC Corporation. It operates at a frequency of 125 MHz and requires a supply voltage of 3.3 V. The device supports LVPECL output logic levels, ensuring compatibility with high-speed digital interfaces. It is designed for surface mount installation within a compact 7 mm x 5 mm package. The component functions reliably across an extended industrial temperature range from -40°C to +85°C.

Oscillators Feature Summary

Provides precise frequency generation via voltage control mechanism
Delivers LVPECL output signals for high-speed data transmission
Supports surface mount technology for automated assembly

Oscillators Applications

High-speed serial communication interface clocking
Data acquisition system timing references
Telecommunications equipment synchronization

Oscillators Procurement Notes

Verify the specific output configuration and pinout against the official datasheet before integration. Confirm that the 3.3V supply rail meets the current requirements for LVPECL operation. Ensure the PCB footprint matches the 6-SMD no-lead package dimensions. Validate thermal management strategies for the specified operating temperature range.

Oscillators Selection Notes

Select this component when a fixed 125 MHz reference with voltage tuning capability is required. Consider the LVPECL output format for signal integrity in high-frequency designs. Evaluate the 7 mm x 5 mm package size against available board space constraints. Compare performance metrics against other VCXOs if broader tuning ranges are necessary.

Oscillators Part Context

This part belongs to the BJA series of voltage controlled crystal oscillators from TXC Corporation. The series focuses on providing stable frequency sources with adjustable characteristics for specialized applications. The BJA2500001 represents a specific frequency point within this family, tailored for 125 MHz operations.
