BK010-10-C-0850-0864-0508-G

Headers, Male Pins Overview

The BK010-10-C-0850-0864-0508-G is a surface mount board-to-board header manufactured by GCT. It features a 10-position configuration with a 5.08mm pitch. The connector utilizes a vertical orientation for PCB integration and employs tin plating on the contacts to ensure reliable electrical connections. Designed for high-density applications, this component supports automated assembly processes typical of modern electronics manufacturing.

Headers, Male Pins Feature Summary

• Surface mount technology enables direct attachment to printed circuit boards
• Vertical design facilitates compact board stacking or edge connections
• Tin-plated contacts provide corrosion resistance and stable conductivity

Headers, Male Pins Applications

• Board-to-board interconnections in industrial equipment
• Mezzanine card interfaces in computing hardware
• High-density electronic module assemblies

Headers, Male Pins Procurement Notes

Verify the specific pin count and pitch requirements against the target PCB footprint before ordering. Confirm that the tin plating specification meets the environmental and solderability standards required for the final assembly process. Ensure compatibility with standard surface mount reflow profiles to maintain connection integrity during manufacturing.

Headers, Male Pins Selection Notes

Select this component when a vertical, surface-mount solution is required for connecting two parallel boards. The 5.08mm pitch offers a balance between spacing and density suitable for power or signal transmission. Consider the mechanical stability provided by the vertical form factor in vibration-prone environments compared to horizontal alternatives.

Headers, Male Pins Part Context

This part belongs to GCT's series of board-to-board and mezzanine connectors. These components are engineered for robust interconnectivity in space-constrained designs. The product line emphasizes reliability and ease of automation, catering to industries requiring precise alignment and secure mating between circuit boards.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 10-position count, 5.08mm pitch, vertical orientation, and surface mount package. Verify that alternative headers offer compatible tin plating and identical mechanical dimensions to ensure proper fit within the existing enclosure and PCB layout constraints.
