BKT-141-01-F-V-S

Headers, Male Pins Overview

The BKT-141-01-F-V-S is a surface mount rectangular header connector manufactured by Samtec Inc. It features 41 positions arranged in two rows with a 1.00mm (0.039 inch) mating pitch and 2.54mm (0.100 inch) row spacing. The contacts are male pins made of phosphor bronze with a 3.00µin gold plating thickness, rated for 2.8A per contact. The black LCP insulator provides UL94 V-0 flammability rating and operates within a -55°C to 125°C temperature range. The assembly includes a four-wall shielded shroud and utilizes a push-pull locking mechanism for secure board-to-board connections.

Headers, Male Pins Feature Summary

• Push-pull locking mechanism ensures secure retention during vibration
• Four-wall shielded shroud design supports signal integrity
• Surface mount termination facilitates automated PCB assembly

Headers, Male Pins Applications

• High-density board-to-board interconnects
• Industrial control systems requiring robust mechanical retention
• Telecommunications equipment with shielding requirements

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against the official Samtec datasheet to ensure compatibility with required shroud and termination specifications. Confirm that the surface mount footprint matches the target PCB layout dimensions. Check RoHS compliance status if environmental regulations apply to the final assembly. Ensure mating connectors utilize compatible pin configurations and current ratings.

Headers, Male Pins Selection Notes

Select this component when a high-reliability connection with mechanical locking is necessary. The 1.00mm pitch allows for dense pin counts in limited space. The four-wall shield provides EMI protection compared to open designs. Verify that the 2.8A current rating meets the circuit requirements. Consider the operating temperature range for harsh environments.

Headers, Male Pins Part Context

This part belongs to the BKT series of surface mount headers from Samtec. The series offers various position counts and shroud options. The BKT-141-01-F-V-S specifically denotes a 41-position variant with a standard shroud and gold-plated contacts. It is designed for applications demanding precise alignment and secure physical connection between stacked boards.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Samtec BKT series headers with identical 41-position, 1.00mm pitch, and push-pull locking features. Cross-brand replacements require matching the 2.54mm row spacing and 3.90mm insulation height. Verify that alternative components support the same current rating and thermal performance.

Headers, Male Pins FAQ

What is the purpose of the push-pull locking feature?

It provides a secure mechanical connection that resists vibration and accidental disengagement.

Does this connector include shielding?

Yes, it features a four-wall shielded shroud to assist with electromagnetic interference protection.
