BKT-169-01-L-V-P

Headers, Male Pins Overview

The BKT-169-01-L-V-P is a 69-position surface mount header from the Samtec BKT series, featuring a 1.00 mm (0.039 inch) pin spacing and dual rows. Constructed with phosphor bronze contacts and LCP insulation, it utilizes Tiger Claw™ contact technology for secure board retention. The connector supports a mating height range of 4.14 mm to 7 mm and offers five standard stack height options. Rated for 2.8 A per contact, it operates within a temperature range of -55°C to 125°C and meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Tiger Claw™ contact design ensures reliable surface mount retention without additional locking mechanisms
• Compatible with BKS series sockets for standardized 1.00 mm pitch interconnect solutions
• Available in multiple stack heights to accommodate varying board-to-board clearance requirements

Headers, Male Pins Applications

• High-density board-to-board connections in compact electronic assemblies
• Industrial control systems requiring robust surface mount headers
• Telecommunications equipment utilizing standardized 1mm pitch interfaces

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required configuration, including pin count, row arrangement, and termination type. Confirm compliance with RoHS and REACH regulations if applicable to your manufacturing region. Ensure that the selected stack height aligns with the mechanical constraints of the target assembly. Cross-reference the datasheet for accurate CAD models and footprint dimensions prior to finalizing the design.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-reliability surface mount header is required for dense circuit layouts. The 1.00 mm pitch allows for significant I/O density within limited board areas. Consider the available stack height options to ensure proper mating with corresponding BKS series sockets. Verify thermal and current ratings against the application's operational demands to guarantee long-term performance stability.

Headers, Male Pins Part Context

This component belongs to the BKT series of 1.00 mm pitch surface mount headers designed by Samtec Inc. The series is engineered for applications demanding high reliability and space efficiency. It pairs specifically with the BKS series sockets, creating a complete interconnect system. The design emphasizes ease of assembly through surface mount technology while maintaining electrical integrity in demanding environments.

Headers, Male Pins Replacement Considerations

Direct substitutes include other BKT series headers with identical pin counts and pitch, such as BKT-169-01-L-V-S-P. Alternative Samtec parts may vary in stack height or contact plating. Ensure any replacement maintains the 1.00 mm spacing and dual-row configuration to preserve mechanical fit and electrical compatibility with existing BKS mates.
