BL-BKC3V1G-AT

Overview

The BL-BKC3V1G-AT is a single-color Super Yellow LED manufactured by American Bright Optoelectronics Corporation. It utilizes a T-1 (3mm) radial mount package with a water clear lens. The component emits light at a peak wavelength of 590 nm. Key electrical parameters include a maximum forward current of 30 mA, a typical forward voltage of 2 V, and a nominal luminous intensity of 3.2 cd. The device operates within a temperature range of -40 °C to +85 °C.

Feature Summary

• Emits super yellow light at a 590 nm peak wavelength
• Features a water clear dome lens for visibility
• Designed for standard radial through-hole mounting

Applications

• Electronic circuit board status indication
• Monitor and TV set power indicators
• Computer hardware signaling

Procurement Notes

Verify the specific suffix 'AT' against official manufacturer documentation to confirm lead time and tape-and-reel packaging specifications. Ensure the ordering part number matches the required luminous intensity binning and forward voltage characteristics listed in the latest datasheet before finalizing procurement orders.

Selection Notes

Select this component for applications requiring a 3mm through-hole yellow indicator. Consider the 30 mA absolute maximum rating and 2 V typical forward voltage when designing current-limiting circuits. Verify that the 30-degree viewing angle and 3.2 cd intensity meet the visibility requirements of the target enclosure.

Part Context

This component belongs to the BL series of single-color LEDs from American Bright Optoelectronics Corporation. It shares the standard T-1 form factor with other variants like the BL-BGX3V1 but differs in emission color and optical output. The series is designed for general-purpose visual indication in consumer electronics.

Replacement Considerations

Cross-reference with BL-BKC3V1 for basic package compatibility. Verify if the BL-BKC3V1G-AT's specific intensity and voltage ratings are met by alternative suppliers' 3mm yellow LEDs.
