BL02RN2R1P1A

Chip Ferrite Bead Overview

The BL02RN2R1P1A is a ferrite bead with leads from the Murata BL02 series, designed for high-frequency noise suppression. It features a split radial bend termination style and operates within a temperature range of -40°C to +85°C. The component supports a maximum DC current of 6 A and has a maximum DC resistance of 20 mΩ. Its physical dimensions include a depth of 3.6 mm.

Chip Ferrite Bead Feature Summary

• Provides high-frequency loss for effective noise suppression in circuits
• Features lead wires with split radial bend termination for through-hole mounting
• Constructed as a single-function ferrite bead component

Chip Ferrite Bead Applications

• High-frequency noise suppression in electronic circuits
• Through-hole mounting applications requiring leaded ferrite beads
• Power line filtering where low DC resistance is required

Chip Ferrite Bead Procurement Notes

Verify the specific manufacturing lot and RoHS compliance status directly with Murata Electronics or authorized distributors before procurement. Confirm that the split radial bend package matches your PCB footprint requirements. Ensure the operating temperature range meets your system's environmental conditions. Check for any end-of-life notices or alternative part recommendations if long-term supply stability is critical for your production timeline.

Chip Ferrite Bead Selection Notes

Select this component when through-hole mounting is preferred over surface mount technology for ferrite beads. The 6 A current rating makes it suitable for power lines with moderate current loads. The 20 mΩ maximum DC resistance minimizes voltage drop across the component. Consider the split radial bend form factor for ease of manual assembly or specific mechanical constraints that require bent leads.

Chip Ferrite Bead Part Context

This component belongs to the Murata BL02 series of ferrite beads with leads. These parts are engineered to produce high-frequency loss for noise suppression. The series typically includes various impedance characteristics and current ratings to suit different circuit requirements while maintaining a consistent leaded package format for reliable through-hole integration.

Chip Ferrite Bead Replacement Considerations

Consult Murata official documentation for direct substitutes within the BL02 series or compatible ferrite bead families. Verify that any replacement maintains the same split radial bend termination and current handling capabilities. Cross-reference impedance curves and DC resistance values to ensure equivalent noise suppression performance in the target application.
