BMQA000606304R7MA1

Fixed Inductors Overview

The BMQA000606304R7MA1 is a shielded molded power inductor from Pulse Electronics, designed for surface mount applications. It features an inductance of 4.7 µH with a tolerance of ±20%. The component supports a maximum DC current of 6 A and a saturation current of 6.5 A. Its maximum DC resistance is 22 mΩ. The package dimensions are 6.86 mm x 6.47 mm x 3 mm. It operates within a temperature range of -55°C to +125°C.

Fixed Inductors Feature Summary

• Shielded molded construction minimizes electromagnetic interference
• Optimized efficiency through low AC resistance at light loads and low DC resistance at heavy loads
• High saturation current capability for robust power handling

Fixed Inductors Applications

• Automotive electronics systems
• Point-of-load voltage regulation
• General power supply circuits

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm exact electrical characteristics and packaging options. Ensure that any alternative part numbers or aliases match the required inductance, current ratings, and physical footprint before finalizing procurement decisions.

Fixed Inductors Selection Notes

Select this component when a compact shielded inductor with high current capacity is required. The low profile and small footprint suit space-constrained designs. Verify thermal management requirements given the operating temperature range and current ratings for the specific application environment.

Fixed Inductors Part Context

This part belongs to the BMQA series of mini molded power inductors by Pulse Electronics. The series focuses on improving efficiency performance through optimized magnetic circuit design. It targets applications requiring reliable power filtering in compact form factors.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
