BMYD890G

$136.48

Description：RF ANT 925MHZ YAGI N TYPE F POLE
Series：BMYD
Mfr：Amphenol PCTEL
Package：Box

SKU:5ec5599b052c Category: RF Antennas Brand: Amphenol PCTEL

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

BMYD890G is listed in the Antennas RF range at ChipApex. The manufacturer field lists Amphenol PCTEL. Its product description is RF ANT 925MHZ YAGI N TYPE F POLE. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for BMYD890G

Description：RF ANT 925MHZ YAGI N TYPE F POLE
Series：BMYD
Mfr：Amphenol PCTEL
Package：Box
RF Family/Standard：General ISM
Frequency Group：UHF (300MHz ~ 1GHz)
Frequency (Center/Band)：925MHz
Frequency Range：890MHz ~ 960MHz
Antenna Type：Yagi, 3-Element
Number of Bands：1
VSWR：-
Return Loss：-
Gain：6.5dBd
Features：Cable - 609.6mm
Termination：N Type Female
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Pole Mount
Height (Max)：12.000" (304.80mm)
Applications：ISM, LoRa, LPWAN
Power - Max：200 W

Antennas RF datasheet and documents for BMYD890G

BMYD890G

Antennas RF Overview

The BMYD890G is a three-element Yagi antenna designed for the UHF frequency group, specifically covering the 890 MHz to 960 MHz band. It provides a gain of 6.5 dBd and supports a maximum power input of 200 W. The unit features an N-type female connector attached to a 2-foot pigtail cable. Designed for pole mounting, the antenna has a maximum height of 12.000 inches (304.80 mm) and includes necessary mounting hardware.

Antennas RF Feature Summary

Three-element Yagi design for high gain performance
Broadband operation within the 890-960 MHz range
Integrated 2-foot pigtail with N-type female termination
Includes mounting hardware for pole installation

Antennas RF Applications

Industrial IoT wireless communication systems
UHF radio base station links
Point-to-point data transmission networks

Antennas RF Procurement Notes

Verify that the specific order includes the 2-foot pigtail cable and mounting hardware as standard components. Confirm the N-type female connector compatibility with existing coaxial cables. Ensure the operating environment falls within the specified UHF frequency range of 890-960 MHz to maintain optimal gain and performance levels.

Antennas RF Selection Notes

Select this model when broadband coverage across 890-960 MHz is required rather than a single fixed frequency. Choose the BMYD890G for applications needing 6.5 dBd gain with integrated cabling. Consider the 200 W power rating for moderate transmission requirements. Verify pole mounting constraints against the 12-inch height specification.

Antennas RF Part Context

This component belongs to the PCTEL BlueWave series, engineered for premium quality industrial IoT solutions. Amphenol PCTEL specializes in purpose-built wireless technology, including antenna systems and test equipment. The BMYD890G represents a high-gain, broadband solution within their UHF portfolio.
