BP0BA2150A700

Overview

The BP0BA2150A700 is a bandpass RF filter manufactured by KYOCERA AVX, designed for signal conditioning applications. It operates at a center frequency of 2150 MHz with an 829 MHz bandwidth. The component features a 5 dB insertion loss and maintains a 50 Ohm impedance. It utilizes SMD/SMT termination types and is housed in a 19-SMD, No Lead package configuration.

Feature Summary

• Provides precise bandpass filtering for radio frequency signals
• Utilizes surface mount technology for board integration
• Engineered for high-frequency signal conditioning

Applications

• Wireless communication systems
• RF signal processing circuits
• Telecommunications infrastructure

Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with KYOCERA AVX before procurement. Confirm that the 19-SMD package dimensions align with your PCB footprint requirements. Ensure the operating temperature range meets your environmental specifications. Check for any recent discontinuation notices or lifecycle changes associated with this part number to avoid supply chain disruptions during production.

Selection Notes

Select this component when a 2150 MHz center frequency and 829 MHz bandwidth are required for RF filtering. The 5 dB insertion loss specification should be evaluated against system sensitivity requirements. The 50 Ohm impedance matches standard RF transmission lines. Consider the 19-SMD package size for space-constrained designs requiring surface mount assembly without leaded components.

Part Context

This component belongs to the KYOCERA AVX RF filter portfolio, which includes various bandpass and high-pass filters for microwave applications. The BP series typically utilizes thin-film multilayer technology for stable performance. These filters are designed to meet the rigorous demands of modern wireless communication standards and industrial RF equipment.

Replacement Considerations

Consult official KYOCERA AVX documentation for verified substitute part numbers. Cross-reference electrical parameters such as center frequency, bandwidth, and insertion loss to ensure compatibility. Verify package dimensions and pinout configurations before substituting.
