Product Detailed Parameters
- Description：RF FILTER BANDPASS 2.5GHZ 30ULGA
- Series：BP
- Mfr：KYOCERA AVX
- Package：Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT)
- Frequency：2.5GHz
- Bandwidth：1.08GHz
- Filter Type：Band Pass
- Ripple：-
- Insertion Loss：1.19dB
- Mounting Type：Surface Mount
- Package / Case：30-ULGA
- Size / Dimension：0.460" L x 0.170" W (11.68mm x 4.32mm)
- Height (Max)：0.022" (0.56mm)
Download product information
Overview
The BP0EA2500A7TR is a surface-mount bandpass filter from the KYOCERA AVX MLO series, designed for signal conditioning in RF applications. It operates at a center frequency of 2.5 GHz with a bandwidth of 1.08 GHz. The component features a 50 Ohm impedance and an insertion loss of 1.19 dB. It utilizes SMD/SMT termination and is housed in a 30-ULGA package. The device supports board mounting and functions within a temperature range of -55°C to +85°C.
Feature Summary
- Provides selective frequency filtering for radio frequency signals
- Optimized for low insertion loss performance
- Designed for high-reliability surface-mount integration
Applications
- Wireless communication systems
- RF front-end modules
- Telecommunications equipment
Procurement Notes
Verify current availability status directly with authorized distributors or the manufacturer, as supply chain conditions may vary. Confirm that the specific ordering suffix matches the required reel quantity and packaging configuration. Ensure compatibility with existing PCB footprint specifications before finalizing procurement orders to avoid integration issues.
Selection Notes
Select this component when a 2.5 GHz center frequency and 1.08 GHz bandwidth are required for signal conditioning. Consider the 30-ULGA package size for space-constrained designs. Evaluate the 1.19 dB insertion loss against system sensitivity requirements. Verify that the operating temperature range meets environmental constraints for the intended deployment scenario.
Part Context
This part belongs to the KYOCERA AVX MLO family of microwave filters. These components are engineered for robust performance in demanding RF environments. The series offers various configurations tailored to different frequency bands and bandwidth requirements, supporting diverse electronic applications across industrial and commercial sectors.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Consult official engineering change notices or distributor cross-reference tools for potential alternatives if discontinuation occurs.
