BP0FA1190A700

Overview

The BP0FA1190A700 is a bandpass RF filter manufactured by KYOCERA AVX, designed for radio frequency signal conditioning. It operates at a center frequency of 1.19 GHz with a bandwidth of 450 MHz. The component exhibits an insertion loss of 1.56 dB and utilizes a 31-ULGA surface mount package. Its physical dimensions are 21.99 mm in length, 5.25 mm in width, and a maximum height of 0.56 mm.

Feature Summary

• Provides bandpass filtering characteristics for RF applications
• Utilizes surface mount technology for board integration
• Engineered for specific center frequency operation

Applications

• Radio frequency signal conditioning
• RF filter circuits

Procurement Notes

Verify the current manufacturing status and availability directly with KYOCERA AVX or authorized distributors before procurement. Confirm that the 31-ULGA package dimensions and electrical specifications align precisely with the design requirements. Ensure compliance with relevant environmental standards and check for any product discontinuation notices or lifecycle changes affecting long-term supply stability.

Selection Notes

Select this component when a bandpass filter centered at 1.19 GHz with a 450 MHz bandwidth is required. The 1.56 dB insertion loss specification should be evaluated against system link budget constraints. The 31-ULGA surface mount package must fit within the available PCB real estate, considering the 21.99 mm x 5.25 mm footprint and 0.56 mm height limit.

Part Context

This part belongs to the KYOCERA AVX RF filter portfolio, which includes various passive components for signal processing. The manufacturer specializes in electronic devices such as capacitors, crystal units, and SAW devices. This specific model represents a thin-film or similar advanced filtering technology solution offered by the company for high-frequency applications.
