BPCF001313753R9T00

$0.47

Description：INDUCTOR POWER
Series：BPCF
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:3690f8a27850 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

BPCF001313753R9T00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR POWER. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for BPCF001313753R9T00

Description：INDUCTOR POWER
Series：BPCF
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：-
Material - Core：Ferrite
Inductance：3.9 µH
Tolerance：±30%
Current Rating (Amps)：6.7 A
Current - Saturation (Isat)：9A
Shielding：Shielded
DC Resistance (DCR)：10.4mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max)：0.309" (7.85mm)
Features：-

Fixed Inductors datasheet and documents for BPCF001313753R9T00

BPCF001313753R9T00

Fixed Inductors Overview

The BPCF001313753R9T00 is a surface-mount power inductor from Pulse Electronics, part of the Chilisin Power series. It features a shielded ferrite core and wirewound construction designed for high-current applications. The component measures 12.5 mm x 12.5 mm x 8 mm and utilizes standard SMD/SMT termination styles. Key electrical specifications include an inductance of 3.9 uH with a tolerance of 30%. It exhibits a maximum DC resistance of 15 mOhms and supports a saturation current of 19.4 A. The device operates within a temperature range of -30°C to +100°C and is supplied in reel packaging.
