BPCI00121260181K00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR POWER. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for BPCI00121260181K00
- Description：INDUCTOR POWER
- Series：BPCI
- Mfr：Pulse Electronics
- Package：Tape & Reel (TR)
- Type：Multilayer
- Material - Core：Ferrite
- Inductance：180 µH
- Tolerance：±10%
- Current Rating (Amps)：900 mA
- Current - Saturation (Isat)：900mA
- Shielding：Shielded
- DC Resistance (DCR)：290mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.472" L x 0.472" W (12.00mm x 12.00mm)
- Height - Seated (Max)：0.236" (6.00mm)
- Features：-
Fixed Inductors datasheet and documents for BPCI00121260181K00
Fixed Inductors Overview
The BPCI00121260181K00 is a surface-mount power inductor from Pulse Electronics, designed for PCB mounting. It features a ferrite core and shielded construction to minimize electromagnetic interference. The component has an inductance of 1.8 mH with a tolerance of 10%. It supports a maximum DC current of 580 mA and has a maximum DC resistance of 2 Ohms. The operating temperature range spans from -40°C to +125°C. The physical dimensions are 12 mm x 12 mm x 6 mm.
Fixed Inductors Feature Summary
- Shielded design reduces magnetic field interference
- Ferrite core material ensures stable performance
- Surface mount termination style for automated assembly
Fixed Inductors Applications
- Automotive electronics systems
- Power supply filtering circuits
- DC-DC converter applications
Fixed Inductors Procurement Notes
Verify the specific manufacturer part number against official Pulse Electronics documentation to ensure compatibility. Confirm that the shielding type and core material meet the electromagnetic interference requirements of the target application. Check the maximum DC current and saturation limits against circuit load conditions. Ensure the operating temperature range aligns with the environmental specifications of the final device.
Fixed Inductors Selection Notes
Select this component when a shielded power inductor with moderate inductance is required for space-constrained designs. The 12mm x 12mm footprint offers a balance between current handling and board area. Consider the 10% tolerance if precise inductance values are critical for the filter or converter design. Verify that the 2 Ohm DC resistance meets efficiency targets for the specific power rail.
Fixed Inductors Part Context
This part belongs to the Pulse Electronics power inductor portfolio, specifically utilizing Chilisin Power manufacturing technology. It is categorized under SMD power inductors with ferrite cores. The product line focuses on providing reliable magnetic components for automotive and industrial applications where shielding and thermal stability are essential.
Fixed Inductors Replacement Considerations
Consult official distributor databases for cross-referenced parts. Verify that any substitute matches the 1.8 mH inductance, 12x12x6 mm package, and shielded configuration. Ensure the replacement maintains the same electrical characteristics and thermal ratings.
