BPF2520LL03R2400A

Overview

The BPF2520LL03R2400A is a surface-mount bandpass filter manufactured by Pulse Electronics. It operates at a center frequency of 2.4 GHz and is designed for signal conditioning applications. The component utilizes a 2520 package size, suitable for compact PCB layouts. It supports SMD/SMT mounting with solder termination. The device is rated for an operating temperature range from -40°C to +85°C. It complies with RoHS standards and is intended for use in wireless communication systems requiring precise frequency selection.

Feature Summary

• Provides selective frequency filtering for 2.4 GHz signals
• Compact 2520 surface-mount footprint for space-constrained designs
• Supports board-mounted installation via solder termination

Applications

• Wireless LAN (WLAN) modules
• Bluetooth devices
• Zigbee transceivers
• IoT sensor nodes

Procurement Notes

Verify the specific datasheet revision and mechanical dimensions against your PCB layout requirements before ordering. Confirm that the 2520 package size aligns with your assembly capabilities. Ensure the operating temperature range meets your environmental specifications. Cross-reference the manufacturer part number with authorized distributors to ensure authenticity. Check for any recent design changes or obsolescence notices from Pulse Electronics.

Selection Notes

Select this component when a dedicated 2.4 GHz bandpass filter is required for noise reduction in short-range wireless links. Consider the 2520 package constraints regarding available board real estate. Evaluate insertion loss and rejection characteristics if detailed performance data is available in the official datasheet. Compare against alternative filters based on physical size and integration needs within the RF front-end chain.

Part Context

This part belongs to Pulse Electronics' signal conditioning portfolio, specifically focusing on passive RF components. It complements their antenna and diplexer lines by providing necessary spectral purity for 2.4 GHz ISM band operations. The product is categorized under bandpass filters used in consumer electronics and industrial IoT applications requiring reliable wireless connectivity.

Replacement Considerations

Consult official Pulse Electronics documentation for qualified alternates. Verify compatibility of pinout, impedance, and frequency response with existing designs. Ensure substitute components meet the same thermal and mechanical specifications.
