BPPM00050520102X0E

$0.55

Description：CMC 2.1A 2LN 800 OHM SMD
Series：BPPM
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:06814ce1735f Category: Common Mode Chokes Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 2.1A 2LN 800 OHM SMD
Series：BPPM
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：2.1A
DC Resistance (DCR) (Max)：68mOhm
Voltage Rating - DC：50V
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.185" L x 0.177" W (4.70mm x 4.50mm)
Height (Max)：0.079" (2.00mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：-
Impedance @ Frequency：800 Ohms @ 100 MHz
Qualification：-
Grade：-

Download product information

BPPM00050520102X0E

Overview

The BPPM00050520102X0E is a surface mount common mode choke manufactured by Pulse Electronics. It features a Chilisin Power ferrite core design intended for power line noise countermeasures. The component has an impedance of 800 Ohms and supports a maximum DC current of 2.1 A with a maximum DC resistance of 68 mOhms. It is packaged in reels.

Feature Summary

Surface mount construction for automated assembly
Ferrite core design for effective noise suppression
Shielded configuration to minimize electromagnetic interference

Applications

Power line noise countermeasures
Common mode filtering in electronic circuits

Procurement Notes

Verify the manufacturer part number against official Pulse Electronics documentation to confirm specifications. Ensure compatibility with target PCB footprint and thermal requirements. Check RoHS compliance status via the datasheet. Confirm availability through authorized distributors as supply conditions may vary.

Selection Notes

Select this component based on the required 800 Ohm impedance and 2.1 A current rating. Evaluate the 68 mOhm DC resistance for power loss considerations. Ensure the surface mount package fits the design constraints. Verify that the shielding characteristics meet the system's EMI requirements.

Part Context

This component belongs to the Chilisin Power series of passive components produced by Pulse Electronics. It is categorized under common mode chokes used for signal integrity and noise reduction. The product line focuses on shielded SMD solutions for modern electronics manufacturing.
