BPXX00060625331M00

Fixed Inductors Overview

The BPXX00060625331M00 is a shielded surface-mount power inductor from Pulse Electronics, part of the BPXX series. It features a ferrite core and offers an inductance of 330 µH with a tolerance of ±20%. The component has a maximum DC resistance of 2 Ohms and supports a saturation current of 390 mA. Designed for robust performance, it operates within a temperature range of -40°C to +125°C. The physical dimensions are 6.0 mm x 6.0 mm x 2.5 mm, suitable for compact PCB layouts.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference
• Ferrite core material ensures stable magnetic properties
• Surface-mount design facilitates automated assembly

Fixed Inductors Applications

• DC-DC converter circuits
• Power supply filtering
• General-purpose power electronics

Fixed Inductors Procurement Notes

Verify the manufacturer part number BPXX00060625331M00 against official Pulse Electronics documentation to confirm specifications. Ensure compatibility with RoHS directives if required by your region. Cross-reference datasheet parameters such as inductance and current ratings before integration. Confirm package type and availability status through authorized channels prior to ordering.

Fixed Inductors Selection Notes

Select this component when a 330 µH inductance value is required in a 2424 package size. Consider the 390 mA saturation limit and 2 Ohm resistance for thermal and efficiency calculations. Verify that the operating temperature range meets environmental requirements. Compare against alternative shielded SMD inductors if space or current constraints differ.

Fixed Inductors Part Context

This part belongs to the BPXX series of power inductors manufactured by Pulse Electronics. The series provides various inductance values in standardized surface-mount packages. These components are designed for use in modern electronic devices requiring reliable passive components for power management applications.

Fixed Inductors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data. Consult official distributor databases or manufacturer cross-reference tools for potential alternatives.
