Product Detailed Parameters
- Description：DIODE SCHOTTKY 90V 3A DO214AA
- Series：-
- Mfr：Panjit International Inc.
- Package：Tape & Reel (TR),Cut Tape (CT)
- Technology：Schottky
- Voltage - DC Reverse (Vr) (Max)：90 V
- Current - Average Rectified (Io)：3A
- Voltage - Forward (Vf) (Max) @ If：800 mV @ 3 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：-
- Current - Reverse Leakage @ Vr：50 µA @ 90 V
- Capacitance @ Vr, F：-
- Mounting Type：Surface Mount
- Package / Case：DO-214AA, SMB
- Supplier Device Package：DO-214AA (SMB)
- Operating Temperature - Junction：-65°C ~ 175°C
- Grade：-
- Qualification：-
Download product information
Overview
The BR39_R1_00001 is a Schottky rectifier diode manufactured by Panjit International Inc., designed for surface-mount applications in the DO-214AA (SMB) package. It features a maximum DC reverse voltage of 90 V and an average forward rectified current rating of 3 A. The component utilizes Schottky technology to minimize power loss during operation.
Feature Summary
- Schottky barrier construction for low forward voltage drop
- High surge current capability
- Lead-free finish with RoHS compliance
Applications
- AC-DC converters
- DC-DC converters
- Power supply units
- Free-wheeling diodes
Procurement Notes
Verify the specific suffix R1_00001 against manufacturer datasheets to confirm tape-and-reel packaging specifications. Ensure the SMB footprint matches the design layout. Confirm active status and lead-free compliance requirements prior to final procurement decisions.
Selection Notes
Select this component for circuits requiring efficient rectification at 90 V reverse bias. The 3 A current rating suits moderate power applications. Verify thermal management needs for the SMB package under continuous load conditions.
Part Context
This part belongs to Panjit's discrete Schottky diode portfolio, targeting general-purpose power conversion markets. It complements other SMB-packaged rectifiers within the manufacturer's lineup for consumer and industrial electronics.
Replacement Considerations
Equivalent parts include BR39 variants from other manufacturers offering identical 90 V, 3 A ratings in DO-214AA packages. Verify pinout compatibility and thermal characteristics before substitution.
