BRPG1201W-TR

$0.50

Description：LED GREEN/RED CLEAR SMD
Series：1201W
Mfr：Stanley Electric Co
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:2f56ebb1f6c5 Category: LED Indication - Discrete Brand: Stanley Electric Co

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED GREEN/RED CLEAR SMD
Series：1201W
Mfr：Stanley Electric Co
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Green, Red
Configuration：Independent
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：4.8mcd Green, 12.8mcd Red
Lens Style：Rectangle with Flat Top
Lens Size：1.50mm x 2.50mm
Voltage - Forward (Vf) (Typ)：2.1V Green, 1.7V Red
Current - Test：20mA Green, 20mA Red
Viewing Angle：156°, 149° Green, 160°, 150° Red
Mounting Type：Surface Mount
Wavelength - Dominant：567nm Green, 647nm Red
Wavelength - Peak：560nm Green, 660nm Red
Features：-
Package / Case：4-SMD, No Lead
Supplier Device Package：SMD
Size / Dimension：3.00mm L x 2.50mm W
Height (Max)：1.90mm
Grade：-
Qualification：-

Download product information

BRPG1201W-TR

Overview

The BRPG1201W-TR is a bi-color surface-mount LED from the Stanley Electric Co 1201W series, housed in a 1208 (3216 metric) package. It features green and red emission with peak wavelengths of 555nm and 647nm respectively. The component operates at a forward current of 20mA, with typical forward voltages of 2.1V for green and 1.7V for red. It has a clear colorless lens and offers viewing angles of 160° x 150°. The device is currently obsolete.

Feature Summary

Bi-color configuration combining green and red LEDs within a single compact surface-mount package.

Applications

Status indication in electronic devices requiring dual-state signaling.

Procurement Notes

This component is officially obsolete and no longer manufactured by Stanley Electric Co. Procurement should focus on verified substitute part numbers such as BG1101W-TR or other compatible bi-color SMD LEDs. Verify datasheet compatibility regarding pinout, voltage, and mechanical dimensions before integration into new designs.

Selection Notes

Select this component only for legacy system maintenance or repair where original specifications are mandatory. For new designs, evaluate alternative bi-color LEDs with similar 1208 footprints and comparable electrical characteristics to ensure supply chain stability and long-term availability.

Part Context

Part of the Stanley Electric Co 1201W series, designed for surface-mount technology applications. The BRPG1201W-TR specifically addresses needs for compact dual-color indicators in space-constrained electronics, offering distinct green and red outputs in a standard 1208 footprint.

Replacement Considerations

BG1101W-TR is listed as an available substitute. Verify electrical parameters and mechanical fit against original requirements when transitioning to replacement components.
