BSA5670001

Oscillators Overview

The BSA5670001 is a standard clock oscillator manufactured by TXC Corporation, utilizing a crystal base resonator. It operates at a fixed frequency of 156.25 MHz and supports LVPECL output functionality. The device is designed for a supply voltage of 3.3V and features an enable/disable function. It is rated for an operating temperature range from -5°C to +85°C. This component is classified as an active XO (Standard) type oscillator suitable for precision timing applications requiring stable frequency generation within the specified thermal constraints.

Oscillators Feature Summary

• Provides precise 156.25 MHz signal generation using a crystal base resonator
• Supports LVPECL output interface for high-speed digital systems
• Includes enable/disable control functionality for power management
• Operates reliably within a -5°C to +85°C industrial temperature range

Oscillators Applications

• High-speed data communication interfaces
• Network synchronization equipment
• Telecommunications infrastructure
• Digital signal processing systems

Oscillators Procurement Notes

Verify the specific package dimensions and pinout configuration against your PCB layout requirements before ordering. Confirm that the LVPECL output compatibility matches your receiver input specifications. Ensure the operating temperature range of -5°C to +85°C meets your environmental design criteria. Check for any specific mounting or handling instructions provided in the official datasheet to maintain component integrity during assembly.

Oscillators Selection Notes

Select this oscillator when a stable 156.25 MHz reference is required for LVPECL-compatible circuits. Consider the 3.3V supply requirement and the enable/disable feature for system power optimization. Evaluate the -5°C to +85°C temperature range against your application's thermal environment. Compare phase noise and jitter specifications if available in the full datasheet to ensure compliance with signal integrity standards.

Oscillators Part Context

TXC Corporation specializes in frequency control components, including crystal units and oscillators. The BSA5670001 belongs to their standard clock oscillator lineup, designed for commercial and industrial applications. As an active XO, it integrates the resonator and driver circuitry into a single package, simplifying design implementation compared to discrete crystal solutions.

Oscillators Replacement Considerations

Consult the official TXC Corporation documentation for direct cross-reference part numbers. Verify electrical parameters such as frequency tolerance, load capacitance, and output voltage levels match exactly. Ensure the replacement maintains the same LVPECL output format and physical footprint to guarantee mechanical and electrical compatibility.
