BSCH001608081N0S00

Fixed Inductors Overview

The BSCH001608081N0S00 is a shielded multilayer RF inductor manufactured by Pulse Electronics, designed for surface-mount applications. It features an inductance of 1 nH with a tolerance of 0.3 nH and a maximum DC resistance of 100 mOhms. The component supports a saturation current of 600 mA and operates within a temperature range of -55°C to +125°C. Housed in a 1.6 mm x 0.8 mm x 0.8 mm package, it exhibits a minimum Q factor of 8 and a self-resonant frequency of 10 GHz.

Fixed Inductors Feature Summary

• Shielded multilayer construction utilizing ceramic core material
• Optimized for high-frequency RF signal integrity
• Designed for direct PCB mounting in compact form factors

Fixed Inductors Applications

• RF circuit filtering
• Impedance matching networks
• High-frequency signal processing

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official Pulse Electronics documentation to ensure component authenticity. Confirm that the requested variant matches the required electrical specifications, including inductance value and current ratings. Check for any updated revision codes or suffixes that may affect compatibility. Ensure compliance with relevant environmental standards such as RoHS requirements before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when a low-inductance, shielded solution is required for high-frequency RF paths. The 0603 footprint suits space-constrained designs. Evaluate the 600 mA saturation limit against peak current demands. Consider the 10 GHz self-resonant frequency for operational bandwidth constraints. Verify thermal performance within the specified -55°C to +125°C range for the target environment.

Fixed Inductors Part Context

This component belongs to the BSCH series of RF inductors from Pulse Electronics. It represents a specialized segment of surface-mount magnetic components engineered for radio frequency applications. The series emphasizes miniaturization and shielding to mitigate electromagnetic interference in dense electronic assemblies.

Fixed Inductors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-referencing requires consulting official manufacturer substitution guides or authorized distributor databases for equivalent specifications.
