Product Detailed Parameters
- Description：PWR XFMR LAMINATED 10VA TH
- Series：-
- Mfr：Pulse Electronics
- Package：-
- Type：Laminated Core
- Voltage - Primary：115V, 230V
- Voltage - Secondary (Full Load)：Parallel 12V, Series 24V
- Current - Output (Max)：Parallel 832mA, Series 416mA
- Primary Winding(s)：Dual
- Secondary Winding(s)：Dual
- Center Tap：No
- Power - Max：10VA
- Mounting Type：Through Hole
- Termination Style：PC Pin
- Size / Dimension：53.00mm L x 44.00mm W
- Height - Seated (Max)：28.00mm
- Voltage - Isolation：-
- Weight：0.133 lb (60.33 g)
Download product information
Overview
The BV030-7079.0 is a laminated core power transformer manufactured by Pulse Electronics, designed for through-hole mounting. It features a single primary winding rated for 115V and 230V operation in parallel configuration. The secondary side provides dual outputs: a 12V winding capable of 832mA and a 24V winding capable of 416mA, both configured in series. With a maximum power rating of 10VA, this component utilizes PC pin termination for secure board integration.
Feature Summary
- Dual secondary voltage outputs providing 12V and 24V capabilities
- Laminated core construction for efficient magnetic coupling
- Supports primary voltage selection via parallel connection
Applications
- General purpose AC to DC power supply circuits
- Industrial control system power distribution
- Electronic equipment requiring isolated low-voltage DC rails
Procurement Notes
Verify the specific manufacturing date code against project requirements, as availability may vary due to lifecycle status. Confirm that the parallel primary wiring matches the target input voltage region. Ensure mechanical clearance accommodates the through-hole footprint and height constraints on the final assembly.
Selection Notes
Choose this model when two distinct secondary voltages are required from a single transformer unit. The 10VA rating suits moderate load applications. Verify that the PCB layout supports the necessary spacing for the dual secondary windings and that the thermal environment remains within standard operating limits for laminated core components.
Part Context
This component belongs to the BV030 series of power transformers from Pulse Electronics. The series is characterized by laminated core designs intended for general-purpose isolation and voltage transformation. These units are typically utilized in applications requiring reliable AC-to-DC conversion stages with standardized form factors for easy integration into existing circuit architectures.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation.
