BV201S06006

Overview

The BV201S06006 is a laminated power transformer from the Zettler Magnetics BV series, designed for through-hole mounting. It features a single primary input of 115V and a single secondary output providing 6V at a peak current of 100mA. The unit has a power rating of 0.6VA and utilizes an EE20 core with dimensions of 23.0x24.0mm case size and 19.5mm height. The component is fully encapsulated under vacuum pressure to ensure efficiency and compactness.

Feature Summary

• Fully encapsulated construction under vacuum pressure for enhanced efficiency
• Laminated core design utilizing EE20 geometry
• Through-hole mounting configuration for linear power applications

Applications

• Linear power supply circuits
• General electronic equipment requiring isolated AC-DC conversion
• Control systems utilizing low voltage secondary outputs

Procurement Notes

Verify the specific datasheet version when sourcing this component to confirm regulatory compliance status and exact physical tolerances. Ensure that the procurement channel provides original manufacturer documentation to validate the encapsulation integrity and electrical specifications against the official Zettler Magnetics standards for the BV series.

Selection Notes

Select this transformer for designs requiring a compact, encapsulated solution with a 115V primary input. The 0.6VA rating suits low-power applications where space constraints necessitate the small EE20 form factor. Consider the through-hole package type if PCB assembly methods require leaded components rather than surface mount alternatives.

Part Context

This component belongs to the BV series of encapsulated power transformers manufactured by Zettler Magnetics. The series is characterized by vacuum-pressure encapsulation techniques aimed at reducing size while maintaining performance. These transformers are part of a broader catalog of magnetic components offered by the brand for various power conversion needs.

Replacement Considerations

Cross-reference with other BV series variants such as BV302S06010 or BV201S06008 if different secondary voltages or VA ratings are required. Verify that any substitute maintains the same EE20 core size and through-hole pinout compatibility to ensure mechanical fit within the existing enclosure.
