BWHP00231715R82J00

Fixed Inductors Overview

The BWHP00231715R82J00 is an unshielded surface-mount RF inductor manufactured by Pulse Electronics. It features a wire-wound construction with a ferrite core and operates within a temperature range of -40°C to +125°C. The component has a nominal inductance of 820 nH, a maximum DC resistance of 1.9 ohms, and a rated current of 230 mA. Its physical dimensions are 2.35 mm in length, 1.73 mm in width, and 1.52 mm in height.

Fixed Inductors Feature Summary

• Wire-wound design utilizing a ferrite core for stable RF performance
• Unshielded configuration suitable for general-purpose applications
• Surface-mount package optimized for automated PCB assembly

Fixed Inductors Applications

• RF signal processing circuits
• General-purpose inductive filtering
• High-frequency impedance matching networks

Fixed Inductors Procurement Notes

Verify the specific suffix J00 against official datasheets to confirm tolerance and packaging details. Ensure compatibility with RoHS3 standards and check moisture sensitivity levels prior to storage. Confirm that the 230 mA current rating meets thermal requirements for the target application environment.

Fixed Inductors Selection Notes

Select this component when a compact 820 nH inductance is required for high-frequency applications. Consider the 1.9-ohm DCR and 230 mA current limit for power handling. The unshielded design requires layout consideration to minimize electromagnetic interference with nearby sensitive traces.

Fixed Inductors Part Context

This part belongs to the BWHP series of RF inductors from Pulse Electronics. These components are designed for surface-mount technology and utilize ferrite cores to provide reliable inductance values in small footprints. The series supports various inductance options for diverse RF circuit needs.
