BWLS00100606R22J00

$0.04

Description：INDUCTOR RF
Series：BWLS
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:027646d2c2a3 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

BWLS00100606R22J00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR RF. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for BWLS00100606R22J00

Description：INDUCTOR RF
Series：BWLS
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：220 nH
Tolerance：±5%
Current Rating (Amps)：380 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：530mOhm Max
Q @ Freq：11 @ 50MHz
Frequency - Self Resonant：1.15GHz
Ratings：-
Operating Temperature：-25°C ~ 105°C
Inductance Frequency - Test：50 MHz
Mounting Type：Surface Mount
Package / Case：0402 (1005 Metric)
Supplier Device Package：402
Size / Dimension：0.040" L x 0.022" W (1.02mm x 0.55mm)
Height - Seated (Max)：0.026" (0.66mm)
Features：-

Fixed Inductors datasheet and documents for BWLS00100606R22J00

BWLS00100606R22J00

Fixed Inductors Overview

The BWLS00100606R22J00 is an unshielded surface-mount RF inductor from the Pulse Electronics Chilisin series. It features a ferrite core and wirewound construction within a 0402 (1005 metric) package measuring 1.02 mm x 0.55 mm x 0.56 mm. The component provides an inductance of 22 nH with a 5% tolerance. Key electrical specifications include a maximum DC current of 340 mA, a maximum DC resistance of 1.1 Ohms, and a self-resonant frequency of 1.15 GHz. It operates reliably between -40°C and +105°C.

Fixed Inductors Feature Summary

Utilizes a ferrite core for stable high-frequency performance
Designed for high-reliability applications requiring compact form factors
Unshielded construction suitable for specific RF circuit layouts

Fixed Inductors Applications

RF circuits
High reliability electronics

Fixed Inductors Procurement Notes

Verify the exact inductance value against official datasheets, as similar part numbers may differ significantly. Confirm RoHS compliance status through manufacturer documentation before integration. Ensure the 0402 package dimensions align with PCB footprint requirements. Check operating temperature limits to guarantee functionality within the intended thermal environment.

Fixed Inductors Selection Notes

Select this component when a low-inductance value near 22 nH is required for RF filtering or matching networks. The 0402 package offers space efficiency for dense layouts. Consider the 1.1 Ohm DC resistance and 340 mA current rating to ensure adequate power handling. The unshielded design requires careful placement to minimize electromagnetic interference with adjacent traces.

Fixed Inductors Part Context

This part belongs to the Chilisin RF inductor line manufactured by Pulse Electronics. It is categorized under SMD RF inductors with wirewound technology. The product series emphasizes high reliability and standard termination styles for surface-mount PCB assembly.
