BWQC00322516150TH1

Fixed Inductors Overview

The BWQC00322516150TH1 is a surface-mount RF inductor from Pulse Electronics, designed for high-current applications. It features a wire-wound construction with a ferrite core and measures 3.2 mm x 2.5 mm x 1.6 mm. The component offers an inductance of 15 uH with a tolerance of ±20%. It has a maximum DC resistance of 1.5 Ohms and operates within a temperature range of -25°C to +125°C. The self-resonant frequency is specified at 25 MHz, ensuring performance stability in radio frequency circuits.

Fixed Inductors Feature Summary

• High current handling capability suitable for demanding RF environments
• Wire wound construction on a ferrite core for stable inductance
• Compact surface mount footprint for dense PCB layouts

Fixed Inductors Applications

• RF circuit filtering
• Power supply chokes
• Signal processing modules

Fixed Inductors Procurement Notes

Verify the specific suffix TH1 against official datasheets to confirm tape and reel packaging requirements. Ensure compatibility with standard SMT reflow profiles. Cross-reference the manufacturer part number with authorized distributors to avoid counterfeit components. Confirm RoHS compliance status prior to final procurement decisions.

Fixed Inductors Selection Notes

Select this component when high current capacity is required in a compact RF inductor form factor. The 15 uH value and low DC resistance make it suitable for power filtering applications. Consider the operating temperature range and self-resonant frequency limits during design integration to ensure optimal circuit performance.

Fixed Inductors Part Context

This part belongs to the Chilisin series manufactured under license by Pulse Electronics. It falls under the category of surface-mount RF inductors. The product line emphasizes reliability and performance in wireless communication devices. The specific model utilizes standard termination methods for automated assembly processes.

Fixed Inductors Replacement Considerations

Check for direct substitutes within the same Chilisin series or equivalent high-current RF inductors from other manufacturers. Verify that alternative parts match the 15 uH inductance, 1.5 Ohm DCR, and 3.2x2.5mm package dimensions. Ensure thermal and electrical characteristics align with original design specifications.
