BWVN00322515100T00

$0.13

Description：INDUCTOR POWER
Series：BWVN
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:4854e17e96d5 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

BWVN00322515100T00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR POWER. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for BWVN00322515100T00

Description：INDUCTOR POWER
Series：BWVN
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：Wirewound
Material - Core：-
Inductance：10 µH
Tolerance：±30%
Current Rating (Amps)：700 mA
Current - Saturation (Isat)：750mA
Shielding：Unshielded
DC Resistance (DCR)：380mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：1 MHz
Mounting Type：Surface Mount
Package / Case：1210 (3225 Metric)
Supplier Device Package：1210
Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)：0.067" (1.70mm)
Features：-

Fixed Inductors datasheet and documents for BWVN00322515100T00

BWVN00322515100T00

Fixed Inductors Overview

The BWVN00322515100T00 is a shielded surface-mount power inductor from Pulse Electronics, part of the BWVN series. It utilizes a ferrite core and wire wound construction for high performance. The component features SMD/SMT termination for PCB mounting. It is RoHS compliant, REACH compliant, and halogen-free. The standard factory packaging quantity is 2000 units per reel.

Fixed Inductors Feature Summary

Magnetic shielding design to minimize electromagnetic interference
Ferrite core construction for stable inductance characteristics
Halogen-free composition meeting environmental standards

Fixed Inductors Applications

DC-DC converter circuits
Power supply filtering applications
General-purpose electronic equipment power stages

Fixed Inductors Procurement Notes

Verify the specific suffix 'T00' against official datasheets to confirm tape-and-reel packaging specifications. Ensure compatibility with automated assembly processes. Confirm that the shielded variant matches the design requirements for electromagnetic interference mitigation in the target application environment.

Fixed Inductors Selection Notes

Select this component for applications requiring shielded power inductors with SMD mounting. The ferrite core and wire wound structure support robust power handling. Consider the physical dimensions and thermal characteristics relative to the PCB layout constraints and ambient operating conditions.

Fixed Inductors Part Context

This component belongs to the BWVN series of shielded power inductors manufactured by Pulse Electronics. These components are designed for surface-mount technology (SMT) applications. The series offers various inductance values and current ratings within a standardized footprint family.
