BWVT00201610R47M00

Fixed Inductors Overview

The BWVT00201610R47M00 is a surface-mount power inductor manufactured by Pulse Electronics. It features a shielded design with a ferrite core and standard terminations, housed in a compact 2 mm x 1.6 mm x 1.02 mm package. The component provides an inductance of 470 nH with a tolerance of 20%. It supports a saturation current of 2.9 A and maintains a maximum DC resistance of 72 mOhms. The device operates within a temperature range of -40°C to +125°C and is tested at a frequency of 1 MHz.

Fixed Inductors Feature Summary

• Shielded magnetic circuit construction for reduced electromagnetic interference
• Compact surface-mount footprint suitable for space-constrained designs
• Ferrite core material optimized for high-frequency power applications

Fixed Inductors Applications

• DC-DC converter circuits
• Power supply filtering stages
• General-purpose electronic equipment

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official Pulse Electronics documentation before procurement. Confirm that the component meets all required electrical specifications for the target application. Ensure compliance with relevant environmental standards such as RoHS directives. Check for any specific handling or storage requirements outlined in the datasheet. Validate availability and lead times through authorized distribution channels.

Fixed Inductors Selection Notes

Select this component based on its 470 nH inductance value and 2.9 A saturation current rating. Consider the 72 mOhms DC resistance for efficiency calculations in low-voltage applications. The shielded design is advantageous for sensitive layouts requiring minimal noise coupling. Evaluate the 2 mm x 1.6 mm package size against board space constraints. Ensure the operating temperature range aligns with the environmental conditions of the final product.

Fixed Inductors Part Context

This part belongs to the Pulse Electronics power inductor portfolio, designed for surface-mount technology. It utilizes a closed magnetic circuit type construction to enhance performance in high-density PCB layouts. The component is categorized under SMD power inductors, distinguishing it from unshielded or through-hole alternatives. Its specifications target modern electronics requiring efficient energy storage and filtering in small form factors.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
