BY05-05S30L

BY05-05S30L is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Bellnix Co., Ltd.. Its product description is DC DC CONVERTER 5V 1.5W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for BY05-05S30L

• Description：DC DC CONVERTER 5V 1.5W
• Series：BY-L (1.5W)
• Mfr：Bellnix Co., Ltd.
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.75V
• Voltage - Input (Max)：6V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：300mA
• Power (Watts)：1.5 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-25°C ~ 71°C (With Derating)
• Efficiency：60%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 6 Leads
• Size / Dimension：1.28" L x 0.80" W x 0.41" H (32.6mm x 20.4mm x 10.3mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for BY05-05S30L
