BYH12-200S01

BYH12-200S01 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Bellnix Co., Ltd.. Its product description is DC DC CONVERTER 200V 200MW. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for BYH12-200S01

• Description：DC DC CONVERTER 200V 200MW
• Series：BYH
• Mfr：Bellnix Co., Ltd.
• Package：Bulk
• Type：High Voltage - Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：11V
• Voltage - Input (Max)：16V
• Voltage - Output 1：200V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1mA
• Power (Watts)：200 mW
• Voltage - Isolation：250 V
• Applications：ITE (Commercial)
• Features：Adjustable Output
• Operating Temperature：-10°C ~ 60°C (With Derating)
• Efficiency：-
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 5 Leads
• Size / Dimension：1.28" L x 0.80" W x 0.41" H (32.6mm x 20.4mm x 10.3mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
