BYW99P-200

Diode Arrays Overview

The BYW99P-200 is a dual center tap rectifier diode manufactured by STMicroelectronics. It features two independent cathodes with a common anode configuration, housed in a SOT93 surface-mount package. The device is rated for a maximum repetitive reverse voltage of 200V and supports a continuous forward current of 15A per cathode. Key electrical parameters include a maximum forward voltage of 850mV at 12A and a typical reverse recovery time of 40ns. This component is designed for high-frequency applications requiring efficient power conversion.

Diode Arrays Feature Summary

• Dual center tap configuration with common anode structure
• Optimized for high-frequency switching operations
• Surface-mount SOT93 packaging for compact designs

Diode Arrays Applications

• Switchmode power supplies
• High frequency DC to DC converters
• Efficient DC power conversion circuits

Diode Arrays Procurement Notes

Verify the obsolete status of this specific part number before procurement planning. Confirm availability through authorized distributors or approved substitute components. Ensure that any replacement devices meet the original voltage, current, and thermal specifications required for the design. Check for RoHS compliance and lead-free manufacturing standards if applicable to your assembly process.

Diode Arrays Selection Notes

Select this component when a dual rectifier with a common anode is required for space-constrained designs. The SOT93 package offers a compact footprint suitable for surface-mount technology. Consider the 200V rating and 15A current capacity relative to the circuit's peak load requirements. Evaluate the 40ns reverse recovery time against the switching frequency of the target application to ensure minimal switching losses.

Diode Arrays Part Context

This device belongs to the family of dual center tap rectifiers from STMicroelectronics. Similar variants may exist in different packages such as TOP3I or TO247, offering alternative mounting options while maintaining similar electrical characteristics. The product line targets general-purpose power supply applications where efficiency and size are critical factors.

Diode Arrays Replacement Considerations

The BYW99P-200 is listed as obsolete. Verify available substitutes from the manufacturer or third-party vendors. Ensure replacements match the 200V reverse voltage, 15A current rating, and SOT93 package dimensions. Cross-reference pinouts and thermal resistance values to guarantee functional equivalence in the existing circuit layout.
