C1E-19.200-8-1520-R

Crystals Overview

The C1E-19.200-8-1520-R is a surface-mount crystal oscillator manufactured by Aker Technology Corp. It operates at a fundamental frequency of 19.2 MHz with a tolerance of ±15 ppm. The component features an 8 pF load capacitance and a series resistance of 120 Ohms. It is housed in a compact 4-SMD, No Lead package measuring 0.079 inches in length and 0.063 inches in width. This device is designed for integration into electronic circuits requiring precise timing references.

Crystals Feature Summary

• Provides stable oscillation at 19.2 MHz with ±15 ppm frequency accuracy
• Designed for surface-mount assembly using a 4-SMD no-lead footprint
• Optimized for low power consumption applications

Crystals Applications

• Clock generation for microprocessors and microcontrollers
• Timing reference for communication interfaces
• Frequency control in consumer electronics devices

Crystals Procurement Notes

Verify the specific manufacturer designation, as sources list both Aker Technology Corp and Aker Technology USA. Confirm that the 4-SMD package dimensions match the required 0.079 x 0.063 inch layout. Ensure the load capacitance requirement of 8 pF aligns with the circuit design specifications before finalizing procurement orders.

Crystals Selection Notes

Select this component when a 19.2 MHz timing source is required in space-constrained designs. The 4-SMD package facilitates automated placement. Verify that the ±15 ppm tolerance meets the system's clock accuracy requirements. Consider the 120 Ohm series resistance impact on drive level and circuit stability during the design phase.

Crystals Part Context

This part belongs to the family of surface-mount crystals offered by Aker Technology. Similar models include variants with different tolerances or packaging options, such as the C1E-19.200-8-1015-M. These components are commonly used in digital systems where reliable frequency synthesis is critical for data transmission and processing synchronization.

Crystals Replacement Considerations

Direct substitutes may include other 19.2 MHz SMD crystals from manufacturers like Epson or NDK, provided the pinout and electrical parameters match. Cross-referencing the 4-SMD footprint and 8 pF load capacitance is essential to ensure functional compatibility without redesigning the PCB.

Crystals FAQ

What is the physical size of the C1E-19.200-8-1520-R?

The component measures 0.079 inches in length and 0.063 inches in width.

Does this crystal support lead-free soldering processes?

Yes, it is designed for surface-mount technology compatible with standard reflow soldering profiles.
