Product Detailed Parameters
- Description：3.0mH, 13.0A Rated.
- Series：C20200
- Mfr：ITG Electronics, Inc.
- Package：Tray
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：13A
- DC Resistance (DCR) (Max)：11mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-55°C ~ 105°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：1.772" L x 0.846" W (45.00mm x 21.50mm)
- Height (Max)：1.732" (44.00mm)
- Package / Case：Radial, Vertical - 4 Leads
- Inductance @ Frequency：3 mH @ 1 kHz
- Impedance @ Frequency：-
Download product information
Overview
The C20200-24 is a through-hole common mode choke manufactured by ITG Electronics, Inc. It features an inductance of 3 mH measured at 1 kHz and supports a current rating of 13 A. The component has a DC resistance (DCR) of 11 mOhm. Designed for dual-line applications, it utilizes a core material optimized for common mode noise suppression while maintaining low differential mode impedance.
Feature Summary
- Dual-line configuration for effective common mode noise reduction
- Through-hole mounting for robust mechanical stability
- Low DC resistance to minimize power loss and heat generation
Applications
- Power supply input filtering
- Industrial equipment EMI suppression
- AC line noise attenuation
Procurement Notes
Verify the specific inductance tolerance and saturation current limits against your circuit requirements before ordering. Confirm that the through-hole footprint dimensions match your PCB layout constraints. Ensure the operating temperature range aligns with your system's thermal environment. Request the official datasheet from ITG Electronics for precise electrical characteristics and mechanical drawings.
Selection Notes
Select this component when high current handling capability is required alongside significant common mode noise attenuation. The 13 A rating suits heavy-duty power lines. Compare the 3 mH inductance value against other series variants if lower or higher impedance is needed. Consider the physical size and lead spacing for assembly compatibility.
Part Context
This part belongs to the C20200 series of common mode chokes from ITG Electronics. The series offers various inductance values and current ratings to suit different power levels. The C20200-24 specifically targets high-current applications requiring moderate inductance for EMI compliance.
Replacement Considerations
Check equivalent parts from other manufacturers with similar 3 mH inductance and 13 A current ratings. Verify pinout compatibility and mechanical dimensions before substituting. Ensure the replacement part meets the same safety certifications and performance standards.
