Product Detailed Parameters
- Description：CMC 5.4MH 10A 2LN THROUGH HOLE
- Series：C301306
- Mfr：ITG Electronics, Inc.
- Package：Bulk
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：10A
- DC Resistance (DCR) (Max)：21mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：250V
- Operating Temperature：-40°C ~ 125°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：1.713" L x 1.713" W (43.50mm x 43.50mm)
- Height (Max)：1.024" (26.00mm)
- Package / Case：Horizontal, 4 PC Pin
- Inductance @ Frequency：5.4 mH @ 10 kHz
- Impedance @ Frequency：-
Download product information
Overview
The C301306-542NHF is a two-line common mode choke manufactured by ITG Electronics, Inc., designed for through-hole mounting. It features an inductance of 5.4 mH measured at 10 kHz and supports a maximum current rating of 10 A. The component exhibits a maximum DC resistance (DCR) of 21 mOhm and has an AC voltage rating of 250 V. It withstands 1.5 kV between windings and operates within a temperature range of -40 to +125°C. The unit complies with RoHS and HF standards and utilizes UL 94 V-0 rated materials.
Feature Summary
- Provides common mode noise suppression via dual-line filtering architecture
- Engineered for high-current applications with a 10 A rating
- Constructed with flame-retardant materials meeting UL 94 V-0 standards
- Capable of withstanding 1.5 kV isolation voltage between lines
Applications
- Power supply input filtering
- AC line noise suppression
- EMI reduction in industrial equipment
Procurement Notes
Verify the complete part number including suffixes against official ITG Electronics documentation to ensure correct specifications. Confirm that the through-hole package style matches your PCB layout requirements. Check datasheet details for moisture sensitivity level and operating temperature limits before integration into final assemblies.
Selection Notes
Select this component when a 5.4 mH inductance at 10 kHz is required for common mode noise attenuation. Ensure the circuit design accommodates the 10 A current capacity and 21 mOhm DC resistance. Verify that the 250 V AC rating and 1.5 kV isolation voltage meet the system's electrical safety and insulation requirements.
Part Context
This component belongs to the C301306 series of common mode chokes from ITG Electronics, Inc. The series offers various inductance values tailored for different filtering needs while maintaining consistent mechanical and thermal characteristics suitable for robust electronic environments.
Replacement Considerations
Consult official ITG Electronics substitution guides or equivalent manufacturer cross-reference lists to identify compatible alternatives. Verify that any substitute maintains identical inductance, current rating, and physical dimensions.
